ST Series User’s Manual
3-12
3.4 Ethernet Cable Connector
Use the following drawing to locate your ST unit’s Ethernet connector. The ST Ethernet interface is
IEEE802.3 compatible, and transmits data at 10Mbps. (The Ethernet I/F is equipped on only the ST.)
• It is strongly recommended that your Ethernet network is installed by a trained engineer.
• 1:1 connections using a cross cable may not be possible depending on the type of personal
computer and network card you are using. Make sure to use a hub for connection.
'VJGTPGV+PVGTHCEG$#5'6
56WPKV
$QVVQO
