A module for the direct measurement of two pH values or two redox potentials or pH value and
redox potential via a coaxial cable.
n For the direct connection of pH and ORP sensors
n Maximum cable length: 10 m
Tab. 6: Sensor connection cable, coaxial, for terminal XE1/XE2 and X5/X6
Description Part number
Cable combination, coaxial, Ø 5 mm 0.8 m - SN6 – pre-assembled. 1024105
Cable combination, coaxial, Ø 5 mm 2 m - SN6 – pre-assembled. 1024106
Cable combination, coaxial, Ø 5 mm 5 m - SN6 – pre-assembled. 1024107
7.3.2.3 Module: 2x conductive conductivity/temperature sensors. Part number
734223
A2385
Belegungsvarianten
2x Konduktive Leifähigkeit/
Temperatur
Temperatur
Konduktive Leifähigkeit
Temperatur
Konduktive Leifähigkeit
Kanal 1
Kanal 2
Fig. 23: Module: 2x conductive conductivity/temperature sensors. Part number 734223
A module for the direct measurement of the electrolytic conductivity based on the conductive prin‐
ciple. For the direct connection of 2 electrode conductivity sensors.
Assembly and installation
52
