Promise Technology Pegasus3 R4 User Manual

175
Technology BackgroundPegasus3 Product Manual
Target Requirements
RAID6
Add physical drives. Maximum of 4 (R4), 6 (R6) or 8 (R8).
RAID60
8 physical drives minimum.
See “Migrating a Logical Drive” on page 144.
RAID 6
A RAID 6 Source logical drive can migrate to the following Target logical drives:
RAID 10
A RAID 10 Source logical drive can migrate to the following Target logical drives:
When you migrate RAID 10 logical drive, it becomes RAID 1E by default.
If you want a RAID 10 logical drive, there must be an even number of physical drives and you must
specify RAID 10 for the target logical drive.
See “Migrating a Logical Drive” on page 144.
Target Requirements
RAID0
None.
RAID1E
None.
RAID5
3 physical drives minimum, maximum of 4 (R4), 6 (R6) or 8 (R8). RAID 10
must have less than 4 (R4), 6 (R6) or 8 (R8) physical drives.
RAID6
4 physical drives minimum, maximum of 4 (R4), 6 (R6) or 8 (R8). The RAID
10 logical drive must have less than 4 (R4) or 6(R6) physical drives.
If existing physical drives have no unused space, add 1 or more physical
drives.
RAID10
Add physical drives in multiples of two. Even number of physical drives.
RAID50
6 physical drives minimum.
RAID60
8 physical drives minimum.
Target Requirements
RAID0
None.
RAID1E
Add physical drives.
RAID5
3 physical drives minimum, 4 (R4), 6 (R6) or 8 (R8).
RAID 1E must have less than 4 (R4), 6 (R6) or 8 (R8) physical drives. If
existing physical drives have no unused space, add 1 or more physical
drives.
RAID10
4 physical drives minimum. Even number of physical drives. If existing
physical drives have no unused space, add 1 or more physical drives.
RAID50
6 physical drives minimum.
See “Migrating a Logical Drive” on page 144.
RAID 5
A RAID 5 Source logical drive can migrate to the following Target logical drives:
Target Requirements
RAID0
None.
RAID1E
None.
RAID5
Add physical drives. Maximum of 4 (R4), 6 (R6) or 8 (R8).
RAID6
4 physical drives minimum, maximum of 4 (R4), 6 (R6) or 8 (R8). If
existing physical drives have no unused space, add 1 or more physical
drives.
RAID10
4 physical drives minimum. Even number of physical drives. If existing
physical drives have no unused space, add 1 or more physical drives.
RAID50
6 physical drives minimum.
RAID60
8 physical drives minimum.
See “Migrating a Logical Drive” on page 144.

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
