Promise Technology Pegasus3 R4 User Manual

146
Promise Technology Pegasus3 Series
Viewing a List of Spare Drives
To view a list of spare drives, do one of the following actions:
• From the Dashboard window, click the Spare Drive link.
• From the Storage menu, choose Spare Drive.
Spare Drive information displays, including:
• ID – Spare0, Spare1, etc.
• Status (Normal, Rebuilding or Failed/missing icon)
• CongurableCapacity– Usable capacity of the spare drive
• Physical Drive ID – ID number of the physical drive chosen for this spare
• Revertible – Yes or No
• Spare Type – Global or Dedicated
• Dedicated to Array – ID number of the disk array to which the spare is dedicated
List of Spare Drives

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
