147
Managing the Pegasus3Pegasus3 Product Manual
Viewing Spare Drive Information
To view spare drive information:
1. Do one of the following actions:
• From the Dashboard window, click the Spare Drive link.
• From the Storage menu, choose Spare Drive. The list of spare drives appears.
2. Mouse-over the spare drive you want then click the View button.
Spare Drive information displays, including:
• Spare Drive ID – Spare0, Spare1, etc.
• Physical Drive ID – ID number of the physical drive chosen for this spare
• Location – Enclosure number and slot number
• Model Number – Make and model of the physical drive
• Operational Status – OK, Rebuilding, Failed or Missing
• Spare Type – Global or Dedicated *
• Physical Capacity – Total data capacity of the spare drive
• Revertible – Yes or No *
• CongurableCapacity– Usable capacity of the spare drive
• Spare Check Status – Not Checked or Healthy
• Media Patrol – Enabled or Not Enabled *
• Dedicated to Array – ID number of the disk array to which the spare is dedicated *
Items with an asterisk (*) are adjustable under “Making Spare Drive Settings” on page 150.
For Spare Check, see “Running Spare Check” on page 151.
3. Click the X icon to close the information panel.
Spare Drive informaon

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Promise Technology Pegasus3 R4 and is the answer not in the manual?

Promise Technology Pegasus3 R4 Specifications

General IconGeneral
InternalNo
Chassis typeTower
Cooling typeActive
Device classSmall & Medium Business
Fan diameter92 mm
CertificationCB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product colorBlack
LED indicatorsYes
Number of fans1 fan(s)
Airflow (imperial)70 cfm
Management platformPegasus Utility
Cable lock slot typeKensington
RAID levels0, 1, 1E, 5, 6, 10
Data transfer rate40 Gbit/s
Storage drive size3.5 \
Storage drive capacity4000 GB
Storage drive interfaceSerial ATA
Installed storage drive typeHDD
Supported storage drive typesHDD & SSD
Total installed storage capacity16 TB
Maximum supported storage capacity- TB
Number of storage drives installed4
AC input voltage100-230 V
AC input frequency50 - 60 Hz
Number of power supply units1
Power supply unit (PSU) capacity250 W
Thunderbolt version3
Thunderbolt ports quantity2
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 95 %
Cables includedAC, Thunderbolt
Weight and Dimensions IconWeight and Dimensions
Depth188 mm
Width248 mm
Height195 mm
Weight6800 g
