Promise Technology Pegasus3 R4/R6/R8
Logical Drives
Logical drive technology includes:
• “RAID Levels”
• “RAID Level Migration”
• “Stripe Size”
• “Sector Size”
• “Initialization”
RAID Levels
RAID (Redundant Array of Independent Disks) allows multiple physical drives to be combined together
in a disk array. Then all or a portion of the disk array is formed into a logical drive. The operating system
sees the logical drive as a single storage device, and treats it as such.
RAID 0 – Stripe
When a logical drive is striped, the read and write blocks of data are interleaved between the sectors
of multiple physical drives. Performance is increased, since the workload is balanced between drives
or “members” that form the logical drive. Identical drives are recommended for performance as well as
datastorageefciency.
RAID 0 Striping interleaves data across mulple drives
Physical Drives
Data
Stripe

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
