Promise Technology Pegasus3 Series
Creating a Spare Drive Manually
This feature creates a spare drive only. You can also use the Wizard to create a disk array with logical
drives and spare drives at the same time.
For more information on settings options, see “Spare Drives” on page 183.
To create a spare drive:
1. From the Dashboard window, click the Spare Drive link.
2. Click the Create Spare Drive button.
3. For each of the following items, accept the default or change the settings as required:
• Check the Revertible box if you want a revertible spare drive.
A revertible spare drive returns to its spare drive assignment after you replace the failed
physical drive in the disk array and run the Transition function.
• Type (choose spare type)
• Global – Can be used by any disk array
• Dedicated to a disk array. Click the radio button next to the disk array to which this spare
drive is dedicated.
• Media Type If you have more than one type of physical drive installed (SSD and HDD for
example) choose the type of drive for the spare.
Create Spare Drive - Choose physical drive

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
