IntroductionPegasus3 Product Manual
Storage Disks
The Pegasus3 is shipped with 3.5 inch SATA Hard Disk Drives (HDD) installed in the
drive carriers and placed in the drive bays.
Capacity
The Pegasus3 is available in three form factors that differ in the number of drives that
can be installed. Total capacity depends on the size of the HDD shipped with the unit.
The Pegasus3 R4 is shipped with four HDD
The Pegasus3 R6 is shipped with six HDD
The Pegasus3 R8 is shipped with eight HDD
In addition, Pegasus3 enclosures can be connected or “daisy-chained” to other
Pegasus3 units to scale up the available storage capacity.
Power supply
250WFlex-ATAPowerwith80PlusBronzewithPFC,100-230Vauto-ranging,
50-60Hz AC
System Fan
Pegasus3R4/R6:Dimension:92(W)x92(H)x25(D)mm/Airow:70CFM
Pegasus3R8:Dimension:120(W)x120(H)x25.8(D)mm/Airow:97CFM
RAID function
RAIDlevelsupport:RAID0,1,1E,5,6,10,and
RAID50(Pegasus3R6/R8only)
RAID 60 (Pegasus3 R8 only)
OS Support
MacOS10.12andWindows7,Windows10
Hardware
monitoring
Fan, Temperature, Power, Enclosure, Physical drives, Logical drives, RAID controller
Temperature
Operating: 5° ~ 35° C
Non-operating: -40° ~ 70° C
Humidity
Operating:10%~95%non-condensing
Storage:5%-95%non-condensing
Dimensions
R8:248x188x314mm(9.8x7.4x12.4in)
R6:248x188x235mm(9.8x7.4x9.3in)
R4:248x188x195mm(9.8x7.4x7.7in)
Weight
As shipped with all 3.5” HDD installed:
R8:11kg/24.2lb
R6:9.1kg/20.1lb
R4:6.8kg/15lb
Certication
Safety: CB, UL, cUL, TUV , ,,BSMI, SPRING,BIS
EMC: FCC, CE-EMC, VCCI, BSMI, RCM KCC
Power consumption: ErPLot6(EC,No1275/2008)
SpecificationS

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
