Promise Technology Pegasus3 R4 User Manual

5
IntroductionPegasus3 Product Manual
LED Description
System Status*
The System Status LED located on the Power button lights blue when the Pegasus3
is operating normally. When the system is booting up, this lights orange and will light
blue when fully booted if there are no problems detected. A red System Status LED
indicates a serious problem such as an incomplete array or failed hard disk drive.
Thunderbolt Link
This LED will light blue when the Thunderbolt cable is connected, they remain dark
when there is no link.
Drive Status and
Activity*
The Drive Status LED lights blue when a physical drive is present and functioning
normally. A red Drive Status LED indicates a problem with the physical drive or an
array. The Drive Activity LED lights blue when the physical drive is present and blinks
blue when there is activity on the drive.
* See “CheckingLEDs”onpage191 for more details about using LED indicators for troubleshooting.

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
