Promise Technology Pegasus3 R4 User Manual

6
Promise Technology Pegasus3 R4/R6/R8
Note
As far as the location of the Thunderbolt ports is concerned, the back of the R4, R6
and R8 are identical, i.e. near the top and left of center. The power connection is in
the lower right corner on both devices.
Pegasus3 R6 back view
Main cooling fan
Power supply
cooling fan
Power connection
Thunderbolt 3™
(two ports)
Kensington
Security Slot*
*The Kensington Security Slot is part of an anti-theft system. This allows the user to lock the
Pegasus3 unit to a heavy table or similar object as a theft prevention precaution. You need the
other component of the system - a cable with a Kensington lock - in order to use this.

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
