Promise Technology Pegasus3 R4/R6/R8
Sector Size
A sector is the smallest addressable area on a physical drive. Sector size refers to the number of data
bytesasectorcanhold.Asmallersectorsizeisamoreefcientuseofaphysicaldrive’scapacity.512
bytes (512 B) is the most common sector size, and the default in the Pegasus Utility.
When you create your logical drive using the Wizard Advanced option or you create a logical drive
manually, you can choose a sector size of 512 B, 1 KB, 2 KB, or 4 KB.
See “Creating a Disk Array and Logical Drive with the Wizard” on page 112 and “Creating a Logical
Drive Manually” on page 134.
Initialization
Initialization is done to logical drives after they are created from a disk array. Full initialization sets
alldatabitsinthelogicaldrivetoaspeciedpattern,suchasallzeros.Theactionisusefulbecause
theremayberesidualdataonthelogicaldrivesleftbehindfromearliercongurations.Forthisreason,
Initialization is recommended for all new logical drives.
See “Initializing a Logical Drive” on page 138.

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
