Promise Technology Pegasus3 R4 User Manual

44
Promise Technology Pegasus3 Series
ManagIng tHe Pegasus3
This chapter contains the following topics:
• “Accessing the Pegasus software utility”
• “Managing Subsystems”
• “Managing the RAID Controller”
• “Managing Enclosures”
• “Managing Background Activities”
• “Managing Physical Drives”
• “Managing Disk Arrays”
• “Managing Logical Drives”
• “Managing Spare Drives”
The Pegasus software utility requires a Thunderbolt connection between your computer and the
Pegasus unit. See “Viewing Runtime Events” on page 193, and “Installation and Setup for Windows
Users” on page 19.
The Pegasus management software utility must be installed onto your computer before you can use it.
Note that the management utility

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
