5: Speed information Operation
To call speed values one by one:
o
Expected speed value
(OMNITREND Center).
o
Determined speed value (machine
speed finder)
o
Measured speed value (strobo-
scope, input)
o
Display element for the speed value at the active measurement location.
Icons
Machine speed finder activated. Expected speed is displayed.
Machine speed finder activated. Determined speed is displayed. Reliability
is displayed in percent (%).
Speed is measured. The stroboscope is used for measurement or the meas-
urement is entered.
Measurement location with line speed indicated. Appears in the machine
train list only.
Speed value is specified or calculated via the kinematic model. Machine
speed finder is inactive at this measurement location.
Fault, reference measurement location is missing or kinematic model is in-
valid.
