PRÜFTECHNIK VIBSCANNER 2 User Manual

Note
As long as you do not exit the route, you can execute all measurements on
the route using the ENTER key.
If you would like to stop the measurement during data acquisition, tap
again on the measurement location icon.
The screen is darkened during the meas-
urement.
An animated circle segment shows the
measurement progress.
After measurement completion, the next measurement location on the machine is
called automatically.
Note
Automatic switching is interrupted in the following cases:
o
Route function [Stay on measurement location on...] is activated,
and
o
A threshold is exceeded, which triggers the interruption.
Tap on to switch to the next measurement location.
Repeat the procedure for all other measurement locations on the machine train.
Once all measurements on the machine train are completed, go to the next ma-
chine train.
The following scenarios are possible:
o
Automatic switch: The next machine train is called automatically, if route
function [Go to next machine train after...] is activated (, "Machine train
evaluation" on page 45).
o
Manual switch: Automatic switching is deactivated or suspended due to a
threshold violation. Tap on to switch to the next machine train.
o
Route finished: A summary appears:
60 Edition: 11.2017
4 - Route
