RADWIN2000D+UserManual Release3.6.00 19‐6

RunningtheLinkBudgetCalculator Chapter19

Figure19‐3:RADWIN2000D+LBCmainwindow

2.Chosetherequiredband.ScrolldowntogettoConnectorizedbands.
