Radwin 2000 D+ - Figure 6-10 Change or Add Bands

RADWIN2000D+UserManual Release3.6.00 6‐20
ChangingtheLinkBand Chapter6
MaximumInformationRate
Youcansetseparately,theuplinkanddownlink MaximumInformationRate(MIR)inMbpsor
leaveitasUnlimited. TheMIRactsasathrottle;leavingtheuplinkordownlinkasUnlimited
commitsthelinktooperatingatbesteffort.
VLANandQualityofService
TheseservicesarecoveredrespectivelyinVLANFunctionalityandQualityofService.
6.3.3ChangingtheLinkBand
ChangingtheBandinuseisalwayscarriedoutatthelinklevel(notperinstalledODU).To
changetheLinkBandyoumustbeloggedontotheRT‐A(HBS)asInstaller.InInstallermode,
theToolsdrop‐downmenuhasanextrafunction,ChangeBand.
 TochangetheLinkBand:
1.ClickChangeBand.AlistofavailableBandsisdisplayed:
Figure6‐10:ChangeorAddBands
2.SelecttherequiredBandandclickOK.Forourpurposes,wechoose5.720‐5.960GHz
Universal.Thebandishighlightedandrightbuttonisenabled.
