RADWIN2000D+UserManual Release3.6.00 7‐1

Chapter7:SiteConfiguration

7.1SiteToolBar

Herearethesitetoolbarsandtheirfunctions:

Figure7‐1:SiteToolBars

InthischapterwedescribetheSiteConfigurationwindowindetail,notingdifferences

betweentheRT‐A(HBS)andRT‐B(HSU)sideofLinksitewindow.Wealsocommentbrieflyon

thelastfouritemsinTable 7‐1.

Table7‐1:

Site Buttons - Description

MenuButton

Appliesto

site

Purpose/Reference

Both OpentheSiteConfigurationWindow

Both RecentEvents

Both ActiveAlarms

RT‐A(HBS) DeactivateRT‐A(HBS)

Both ResettheODU

RT‐B(HSU) DeregisterRT‐B(HSU)

RT‐B(HSU) SuspendaDeregisteredRT‐B(HSU)
