RADWIN2000D+UserManual Release3.6.00 4‐2
What’sinthebox Chapter4
• Establishingaradiolink
4.2What’sinthebox
4.2.1UnpackingandChecking
 Foreachoftheitemsbelow:
1.Removetheequipmentfromthebox.
2.CheckthateverythinglistedontheincludedBillofMaterialsorPro‐formaInvoiceis
present.
3.Ifanyitemismissing,contactCustomerService.Youwillbeadvisedwhetherto
returnthepackageforreplacement,orwhetherthemissingitemcanbesupplied
separately.
4.Donotdisposeofthepackaginguntiltheunitisinstalledandoperational.
4.2.2Radios
TheRADWIN2000D+packageincludesthefollowingitems:
• TwoODUs‐seethenextfigureforfrontandrearview
Figure4‐1:ODU‐LargeFormFactors
• TwoODUmountingkits
• ACDcontaining‐
Front Rear
ConnectorizedIntegratedAntenna
