RADWIN2000D+UserManual Release3.6.00 9‐2

RADWINHSS Chapter9

Figure9‐1:Inte rferencecausedbycollocatedunits

AddingHSSremovesinterferenceasshowninthenexttwofigures:

Figure9‐2:CollocatedunitsusingHubSiteSynchronization(1)

Figure9‐3:CollocatedunitsusingHubSiteSynchronization(2)

TheunitsareconnectedtoeachotherwithHSScablesandHSSDistributionUnits.

OneoftheradiosinthesiteisdefinedasHSSMasterandgeneratessynchronizationpulses.

Theothercollocatedradiosinthesite‐theHSSClients,areconnectedtotheHSSMasterand

synchronizetheirtransmissiontothepulses.AnHSSClientcanbeconfiguredtoworkinone

oftwomodes:
