RADWIN2000D+UserManual Release3.6.00 7‐9
Management Chapter7
agementtrafficaff ectsalltypesofmanagementconnections(local,networkand
overtheair).
3.EnteraPrioritynumberbetween0and7.
TheVLANpriorityisusedforthetrafficsentfromtheODUtothemanagingcom‐
puter.
4.ChangetheVLANIDandPriorityofthemanagingcomputerNICtobethesameas
thoseofsteps2and3respectively.
5.ClickApplyorOK.
LostorforgottenVLANID
IftheVLANIDisforgottenorthereisnoVLANtrafficconnectedtotheODU,thenresetthe
relevantODU.
SupportedProtocols
SupportedprotocolsareshowninFigure 7‐5:
Figure7‐5:Supportedprotocols
SNMPsupportispermanentlyenabled.YoumaychoosebetweenSNMPv1,SNMPv3orboth.
IfyouchooseSNMPv3,youwillbeofferedthefollowingcautionarymessage:
Caution
IfthemanagingcomputerisdirectlyconnectedtoanODU,andyouenable
managementVLAN,youwillloseconnectivity.Tologonagain,Youwillneed
toconfigurethemanagingcomputerNICtousethemanagementVLAN
number.
Tip
Duringthefirsttwominutesofconnection,theODUusesmanagement
packetsbothwithandwithoutVLAN.Youmayusethisperiodtoreconfigure
theVLANIDandpriority.
