RADWIN2000D+UserManual Release3.6.00 15‐4
VLANConfigurationUsingtheRADWINManager Chapter15
EgressDirection
15.5VLANConfigurationUsingtheRADWIN
Manager
15.5.1ManagementTrafficandEthernetServiceSeparation
YoucandefineaVLANIDformanagementtrafficseparation.Youshouldconfigurethesystem
topreventconflictsasdetailedbelow.
Whenconfiguredforthedefaultoperationalmode,a“Providerport” willhandleingress
trafficasfollows:
• FiltersframesthatarenottaggedwiththeProviderVLANID
• RemovestheProviderdoubletag
Therefore,ifaportisconfiguredformanagementtrafficseparationbyVLANandas‘Provider
port’,thenthereceivedmanagementframesmustbedoubletaggedasfollows:
Table15‐2:Portsettings‐Egressdirection
Transparent
Theport‘doesnothing’withregardtoVLANs‐outboundframesareleft
untouched.
Untagall
PortconfiguredtountaguserVLADtagsforallframes.
Filter
Disclaimer
IfyouarenotaVLANexpert,pleasebeawarethatincorrectVLAN
configurationma ycausehavoconyournetwork.Thefacilitiesdescribe d
belowareofferedasaservicetoenableyoutogetbestvaluefromyour
RADWIN2000D+linksandareprovided“asis”.Undernocircumstances
does
RADWINacceptresponsibilityfornetworksystemorfinancial
damagesarisingfromincorrectuseoftheseVLANfacilities.
