Radwin 2000 D+ - Figure 4-8 External Antennas for Use with Radwin 2000 D

RADWIN2000D+UserManual Release3.6.00 4‐6
Accessories Chapter4

Figure4‐8:ExternalAntennasforusewithRADWIN2000D+
AntennaKits
ExternalantennasareavailablefortheRADWIN2000D+radios,varyinginoperating
frequencies,formfactor,sizeandgain.
SeetheRADWINproductscatalogforamoredetailedofferingofexternalantennas.External
Atypicalantennakitcontains‐
• Anantenna
• TwoRFcables1.2m(4’)long
• Mountingkit
4.2.7Accessories
HubSiteSynchronizat ion(HSS)Unit
TheHSSunitsynchronizescollocatedODUstopreventselfinterference.Itisparticularly
usefulatamulti‐linkbasestationemployingseveralODUs.
AsingleHSSunitsupportsuptotencollocatedODUs.Inadditiontoeachunitbeing
connectedtoitsPoEdevice,thecollocatedunithasanadditionalcablethatisconnectedto
theHSSUnit.TheHSSUnitisacompact,weatherproof(IP67)connectorboxthatisinstalled
onthesamemastastheODUs.AllcollocatedunitsconnecttothisboxusinganHSScable.
Cablesinpreparedlengthsareavailableforpurchase.
TheHSSunitissuppliedwithtenprotectivecovers;anyportnotinusemustbeclosedwitha
protectivecover.
Caution
The11dBi120°BaseStationsectorialantennasmustbeinstalledwithatiltangleof
atleast32°downwardsrelativetothehorizon.
