RADWIN2000D+UserManual Release3.6.00 15‐5
ConfigurationofVLANTaggingforEthernetService Chapter15
• TheoutertaghastobetheProvider’stag(sotheframeisnotfiltered)
• TheinternaltaghastobemanagementVLANID
Toavoidmix‐ups,bestpracticeisto:
• Separatethemanagementanddataports
• DefineonlyadataportwithProviderfunction
15.5.2ConfigurationofVLANTaggingforEthernetService
 TosetupanHSUforVLANtagging:
1.OpenLinkConfiguration|EthernetandthenclicktheVLANConfigurationbutton.
InDisabledmode,Ethernetframespasstransparentlyovertheradiolinks.
2.ForProvidertagging,clicktheProviderRadiobutton:
InProvidermode,Ethernetframesaretaggedwiththeprovider’sVLANIDbefore
theyenterintotheprovider’snetwork/backbone.
