Remote Control
R&S
®
FPC
189User Manual 1178.4130.02 ─ 07
19.1.1.3 Protocols
VXI-11 basics
The VXI-11 standard is based on the ONC-RPC protocol which in turn relies on TCP/IP
as the network/transport layer. The TCP/IP network protocol and the associated net-
work services are preconfigured. TCP/IP ensures connection-oriented communication,
where the order of the exchanged messages is adhered to and interrupted links are
identified. With this protocol, messages cannot be lost.
Remote control of an instrument via a network is based on standardized protocols
which follow the OSI reference model (see Figure 19-1).
Application
Presentation
Session
Transport
Network
Data Link
Physical
SCPI
XDR (VXI-11)
ONC-RPC
TCP / UDP
IP
Ethernet/802.3
802.3/10BASE-T
Figure 19-1: Example for LAN remote control based on the OSI reference model
Based on TCP/UDP, messages between the controller and the instrument are
exchanged via open network computing (ONC) - remote procedure calls (RPC). With
XDR (VXI-11), legal RPC messages are known as VXI-11 standard. Based on this
standard, messages are exchanged between the controller and the instrument. The
messages are identical with SCPI commands.
They can be organized in four groups
●
Program messages (control command to the instrument)
●
Response messages (values returned by the instrument)
●
Service request (spontaneous queries of the instrument)
●
Low-level control messages (interface messages)
A VXI-11 link between a controller and an instrument uses three channels: core, abort
and interrupt channel. Instrument control is mainly performed on the core channel (pro-
gram, response and low-level control messages). The abort channel is used for imme-
diate abort of the core channel; the interrupt channel transmits spontaneous service
requests of the instrument. Link setup itself is very complex. For more details, refer to
the VXI-11 specification.
