Remote Control
R&S
®
FPC
234User Manual 1178.4130.02 ─ 07
Setting parameters:
<Standard> String containing the file name of the standard.
Make sure to use the correct file extension (for exam-
ple .chpstd for channel power measurements or .obwstd for
occupied bandwidth measurements.
Example: //Select the 3GPP WCDMA standard for channel power mea-
surements
CALC:MARK:FUNC:POW:PRES '3GPP WCDMA.chpstd'
Usage: Setting only
Manual operation: See "Standard" on page 362
See "Standard" on page 365
See "Standard" on page 366
CALCulate<n>:MARKer<m>:FUNCtion:POWer:PRESet:CHECk?
This command checks if the current power measurement settings comply to the set-
tings defined in the currently selected standard.
Prerequisites for this command
●
Select a telecommunications standard for power measurements (CALCulate<n>:
MARKer<m>:FUNCtion:POWer:PRESet).
Note that the command only checks the parameters that are defined by the standard.
Suffix:
<n>, <m>
.
irrelevant
Return values:
<State> 0
R&S FPC settings violate a standard configuration.
1
R&S FPC settings comply with the standard.
Example: //Query compliance to the standard currently in use
CALC:MARK:FUNC:POW:PRES '3GPP WCDMA.chpstd'
CALC:MARK:FUNC:POW:PRES:CHEC?
Usage: Query only
CALCulate<n>:MARKer<m>:FUNCtion:POWer:RESult? <Measurement>
This command queries the results of power measurements.
To get a valid result, you have to perform a complete sweep with synchronization to the
sweep end before reading out the result. This is only possible in single sweep mode.
Prerequisites for this command
●
Select a power measurement (CALCulate<n>:MARKer<m>:FUNCtion:POWer:
SELect).
Remote Commands of the Spectrum Application
