R&S FPC Series User Manual

Remote Control
R&S
®
FPC
280User Manual 1178.4130.02 ─ 07
Parameters:
<SearchLimit> <numeric value>
The unit depends on the measurement: Hz for frequency
domain, seconds for time domain.
Range: The value range corresponds to the maximum
span.
*RST: - (is set to the left diagram border when switching
on search limits)
Example: See CALCulate<n>:MARKer<m>:X:SLIMits<slim>:RIGHt
Manual operation: See "Search Range" on page 377
See "Search Range" on page 387
See "Search Range" on page 405
CALCulate<n>:MARKer<m>:X:SLIMits<slim>:RIGHt <SearchLimit>
This command defines the right limit of the marker search range.
Prerequisites for this command
●
Turn on marker search limits (CALCulate<n>:MARKer<m>:X:
SLIMits<slim>[:STATe]).
If you perform a measurement in zero span, this command limits the evaluation range
on the trace.
Suffix:
<n>, <m>, <slim>
.
irrelevant
Parameters:
<SearchLimit> <numeric value>
The unit depends on the measurement: Hz for frequency
domain, seconds for time domain.
Range: The value range corresponds to the maximum
span.
*RST: - (is set to the left diagram border when switching
on search limits)
Example: //Turn search limits on and define a search range from 10 MHz
to 100 MHz.
CALC:MARK:X:SLIM ON
CALC:MARK:X:SLIM:LEFT 10MHz
CALC:MARK:X:SLIM:RIGH 100MHz
Manual operation: See "Search Range" on page 377
See "Search Range" on page 387
See "Search Range" on page 405
CALCulate<n>:MARKer<m>:X:SLIMits<slim>[:STATe] <State>
This command turns marker search limits on and off.
Remote Commands of the Spectrum Application
