R&S FPC Series User Manual

Remote Control
R&S
®
FPC
321User Manual 1178.4130.02 ─ 07
●
Impedance:
INPut:IMPedance
INPut:IMPedance:PAD
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:PDIVision.................................................... 321
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:RPOSition................................................... 321
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:PDIVision <Scale>
This command defines the range of the y-axis for the graphical results.
Suffix:
<n>
.
irrelevant
<t> irrelevant
Parameters:
<Scale> <numeric value> (integer only)
The unit depends on the result.
• PCT for ASK results (1 % to 100 % per grid division).
• Hz for FSK results (1 kHz to 1 MHz per grid division).
Example: //Define grid scale of AM results (50 percent per grid)
CALC:FEED 'XTIM:DDEM:MEAS'
DISP:TRAC:Y:PDIV 50
Manual operation: See "Deviation per Division" on page 393
DISPlay<n>[:WINDow]:TRACe<t>:Y[:SCALe]:RPOSition <Position>
This command defines the position of the reference level on the display grid.
Prerequisites for this command
●
Select ASK demodulation ([SENSe:]DDEMod).
Suffix:
<n>
.
irrelevant
<t> irrelevant
Parameters:
<Position> <numeric value> (integer)
Range: 1 to 100
*RST: 100
Default unit: PCT
Example: //Define position of reference level
DDEM ASK
CALC:FEED 'XTIM:DDEM:MEAS'
DISP:TRAC:Y:RPOS 80
Manual operation: See "Ref Position" on page 393
Remote Commands of the Digital Demodulation
