Remote Control
R&S
®
FPC
330User Manual 1178.4130.02 ─ 07
Prerequisites for this command
Select cable loss measurement (MEASurement<n>:MODE).
Select cable loss format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Parameters:
<DisplayRange> <numeric value>
*RST: 100
Default unit: dB
Example: //Define display range for cable loss
MEAS:MODE LOSS
MEAS:FORM LOSS
DISP:LOSS:Y:SCAL 50
Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:MAGNitude:REFerence <RefValue>
This command defines the reference value for the return loss measurement format.
Prerequisites for this command
Select reflection, transmission or DTF measurement (MEASurement<n>:MODE).
Select return loss format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Parameters:
<RefValue> <numeric value>
*RST: 0
Default unit: dB or %
Example: //Define reference value for return loss
MEAS:MODE REFL
MEAS:FORM MAGN
DISP:MAGN:REF 50
Manual operation: See "Reference Level" on page 399
DISPlay<n>:MAGNitude:REFerence:POSition <RefPosition>
This command defines the position of the reference value for the return loss measure-
ment format.
Each step shifts the reference position one grid line up or down.
Prerequisites for this command
Select reflection, transmission or DTF measurement (MEASurement<n>:MODE).
Select return loss format (MEASurement<n>:FORMat).
Remote Commands of the VNA Application
