R&S FPC Series User Manual

Remote Control
R&S
®
FPC
331User Manual 1178.4130.02 ─ 07
Suffix:
<n>
.
irrelevant
Parameters:
<RefPosition> <numeric value> (integer only)
*RST: 8
Example: //Define 5th grid line as the reference position for return loss
MEAS:MODE REFL
MEAS:FORM MAGN
DISP:MAGN:REF:POS 5
Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:MAGNitude:Y:SCALe
<DisplayRange>
This command defines the range of the y-axis for the return loss measurement format.
Prerequisites for this command
●
Select reflection, transmission or DTF measurement (MEASurement<n>:MODE).
●
Select return loss format (MEASurement<n>:FORMat).
●
Select a logarithmic scale (DISPlay<n>:MAGNitude:Y:SPACing).
(For a linear scale, the range is always 100 %.)
Suffix:
<n>
.
irrelevant
Parameters:
<DisplayRange> <numeric value>
*RST: 100
Default unit: dB
Example: //Define display range for return loss
MEAS:MODE REFL
MEAS:FORM MAGN
DISP:MAGN:Y:SPAC LOG
DISP:MAGN:Y:SCAL 50
Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:MAGNitude:Y:SPACing <Scaling>
This command selects scaling of the y-axis for the return loss measurement format.
Prerequisites for this command
●
Select reflection, transmission or DTF measurement (MEASurement<n>:MODE).
●
Select return loss format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Remote Commands of the VNA Application
