Remote Control
R&S
®
FPC
332User Manual 1178.4130.02 ─ 07
Parameters:
<Scaling> LINear
Selects a linear scale (in %).
LOGarithmic
Selects a logarithmic scale (in dB).
*RST: LOGarithmic
Example: //Select scaling of the y-axis
MEAS:MODE REFL
MEAS:FORM MAGN
DISP:MAGN:Y:SPAC LIN
Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:PHASe:REFerence
<RefValue>
This command defines the reference value for the phase measurement format.
Prerequisites for this command
Select reflection measurement (MEASurement<n>:MODE).
Select phase format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Parameters:
<RefValue> <numeric value>
Range: -100000 to 100000
*RST: 0
Default unit: deg
Example: //Define reference value for phase
MEAS:MODE REFL
MEAS:FORM PHAS
DISP:PHAS:REF 360
Manual operation: See "Reference Level" on page 399
DISPlay<n>:PHASe:REFerence:POSition <RefPosition>
This command defines the position of the reference value for the phase measurement
format.
Each step shifts the reference position one grid line up or down.
Prerequisites for this command
Select reflection measurement (MEASurement<n>:MODE).
Select phase format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Remote Commands of the VNA Application
