R&S FPC Series User Manual

Remote Control
R&S
®
FPC
333User Manual 1178.4130.02 ─ 07
Parameters:
<RefPosition> <numeric value> (integer only)
Range: 0 to 10
*RST: 8
Example: //Define 5th grid line as the reference position for phase format
MEAS:MODE REFL
MEAS:FORM PHAS
DISP:PHAS:REF:POS 5
Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:PHASe:UNWRap
<State>
This command removes the restriction limiting the value range to +/- 180°.
Suffix:
<n>
.
irrelevant
Parameters:
<State> ON | OFF | 1 | 0
*RST: OFF
Example: //Unwrap phase
DISP:PHAS:UNWR ON
Manual operation: See "Phase" on page 397
DISPlay<n>:PHASe:Y:SCALe <DisplayRange>
This command defines the range of the y-axis for the phase measurement format.
Prerequisites for this command
●
Select reflection measurement (MEASurement<n>:MODE).
●
Select phase format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Parameters:
<DisplayRange> <numeric value>
The number you enter is rounded up to the next possible display
range. For example, if you enter 300°, the R&S FPC automati-
cally sets the display range to 360°.
Range: 90 to 100000
*RST: 360
Default unit: deg
Example: //Define display range for phase
MEAS:MODE REFL
MEAS:FORM PHAS
DISP:PHAS:Y:SCAL 180
Remote Commands of the VNA Application
