Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:VSWR:Y:SCALe <DisplayRange>
This command defines the range of the y-axis for the SWR measurement format.
Prerequisites for this command
●
Select reflection or DTF measurement (MEASurement<n>:MODE).
●
Select SWR format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Parameters:
<DisplayRange> <numeric value>
The number you enter is rounded up to the next possible display
range. For example, if you enter 5, the R&S FPC selects a dis-
play range 1...6.
Range: 1.1 to 71
*RST: 1...21
Default unit: dB
Example: //Define display range for SWR (1...71)
MEAS:MODE DTF
MEAS:FORM VSWR
DISP:VSWR:Y:SCAL 50
Manual operation: See "Range / Ref Position" on page 399
DISPlay<n>:VSWR:Y:SCALe:MAXimum <TopValue>
This command defines the top value of the vertical axis for the SWR measurement for-
mat.
Prerequisites for this command
●
Select reflection or DTF measurement (MEASurement<n>:MODE).
●
Select SWR format (MEASurement<n>:FORMat).
Suffix:
<n>
.
irrelevant
Parameters:
<TopValue> <numeric value>
Range: 1.1 to 71
Example: //Define upper value of the y-axis in SWR
MEAS:MODE DTF
MEAS:FORM VSWR
DISP:VSWR:Y:SCAL:MAX 25
Manual operation: See "Range / Ref Position" on page 399
Remote Commands of the VNA Application
