Raymarine c97 Installation And Operation Handbook

Digitalradarcableextension
Forlongercablerunsaradarpoweranddatadigitalcableextensionisrequired.
D12 2 54-1
1 42
3
1.Radarextensioncable.
2.Radarpoweranddatadigitalcable.
3.Raymarinenetworkswitch(orcrossovercouplerifconnectingradardirectlytodisplay).
4.RayNetcable(orRayNettoSeaT alk
hs
cableifconnectingviacrossovercoupler).
Note:Theextensioncableconnectstotheradarscanner.
Note:ThepowerconnectionisNOTshowninthediagram.IfusinganOpenArrayscanneraVCM(VoltageConverterModule)
mustbeconnectedbetweenthescannerandthepowersupply.
Digitalradarcables
Youwillneedadedicatedradarpoweranddatadigitalcableand
SeaTalk
hs
networkcablestoconnectyourscannertoyoursystem.
ConnectionRequiredcable
Digitalradarscannertopowersupply
andRaymarinenetworkswitch.
Poweranddatadigitalcable.For
longercableruns,extensionsare
availableinavarietyoflengths.
Raymarinenetworkswitchto
multifunctiondisplay.
SeaTalk
hs
networkcables,availablein
avarietyofcablelengths.
Radarpoweranddatadigitalcables
Thesecablescontainthewiresforascanner’spoweranddata
connections.
CablePartnumber
5m(16.4ft)Poweranddatadigital
cable
A55076D
10m(32.8ft)Poweranddatadigital
cable
A55077D
15m(49.2ft)Poweranddatadigital
cable
A55078D
25m(82.0ft)Poweranddatadigital
cable
A55079D
Note:Themaximumlengthfortheradarpoweranddatadigital
cable(includinganyextensions)is25m(82ft).
Radarpoweranddatadigitalextensioncables
Thesecablesextendthepoweranddatadigitalcablesfora
scanner’spoweranddataconnections.
CablePartnumber
2.5m(8.2ft)Poweranddatadigital
cable
A92141D
5m(16.4ft)Poweranddatadigital
cable
A55080D
10m(32.8ft)Poweranddatadigital
cable
A55081D
Note:Themaximumlengthfortheradarpoweranddatadigital
cable(includinganyextensions)is25m(82ft).
Sonarconnection
Asonarconnectionisrequiredforshnderapplications.
Thereare2typesofconnectionrequiredforshnderapplications:
•DigitalSounderModule(DSM)connection—convertsthe
sonarsignalsprovidedbythesonartransducerintodatasuitable
foramarineelectronicssystem.Thesonarvariantmultifunction
displaysfeatureabuilt-inDigitalSounder,enablingyoutoconnect
thedisplaydirectlytoacompatiblesonartransducer.Non-sonar
variantsrequireaconnectiontoanexternalRaymarineDSMunit.
InternalandexternalDigitalsoundersrequireaconnectiontoa
compatiblesonartransducer.
•Sonartransducerconnection—providessonarsignalstothe
DigitalSounderModule(DSM).
Cablesandconnections37
