SonarDSMconnection
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
D12 255 -1
1
2
3
4
1.Rearconnectorpanelofmultifunctiondisplay(Non-sonar
variant).
2.Raymarinenetworkswitch.
3.Raymarine(external)DSMunit
4.RayNetcable.
ThemultifunctiondisplaycanbeusedwiththefollowingDSMunits:
•DSM300
•DSM30
Note:Youcanalsoconnectasonarvariantmultifunctiondisplay
toanexternalDSMunit.Thisisusefulincircumstanceswhere
youneedahigherpoweredDSMforexample.Youcanonlyuse
onesonartransduceratanyonetime.
Sonarconnecteddirectlytothedisplay
Onsmallersystems(withonlyonedisplayandnootherSeaT alk
hs
/
RayNetdevices)theDSMmaybeconnecteddirectlytothedisplay
withoutusingaRaymarinenetworkswitch.
Note:Youmustensurethatthecableendsconnectedintothe
displayandDSMhavealocking/weather-tightmechanism.
Compatiblesonartransducers
Themultifunctiondisplayiscompatiblewiththefollowingsonar
transducers:
•RaymarineP48.
•RaymarineP58.
•MinnKotatransducersSonarvariantRaymarinedisplaysonly),
viaoptionalA62363adaptorcable.
•Any600wattDSM-compatibletransducer,viaoptionalE66066
adaptorcable.
Sonartransducerconnection—Sonarvariantmultifunction
displays
2
D12 256 -1
1
3
1.Rearconnectorpanelofmultifunctiondisplay(Sonarvariant).
2.Sonartransducercable.
3.Sonartransducer.
600wattDSM-compatiblesonartransducerconnectionvia
optionaladaptor—Sonarvariantmultifunctiondisplays
D12 257 -1
1
2
3
1.Rearconnectorpanelofmultifunctiondisplay(Sonarvariant).
2.E66066adaptorcable.
3.Sonartransducer.
Transduceradaptorcable
CablePartnumber
0.5m(1.64ft)transduceradaptor
cable
E66066
Sonartransducerconnection—Non-Sonarvariant
multifunctiondisplays
1
2
SeaTalk
hs
/ RayNet
SeaTalk
hs
/
RayNet
3
6
5
4
D12 258 -1
1.Rearconnectorpanelofmultifunctiondisplay(Non-sonar
variant).
2.Raymarinenetworkswitch(onlyrequiredifconnectingmore
thanonedeviceusingSeaTalk
hs
/RayNet).
3.RayNetcable.
4.RaymarineDSMunit
5.Sonartransducercable.
6.Sonartransducer.
MinnKotasonartransducerconnectionviaoptionaladaptor
cable(Sonarvariantmultifunctiondisplaysonly)
D12 259 -1
1
4
2
3
1.Rearconnectorpanelofmultifunctiondisplay(Sonarvariant).
2.MinnKotatransduceradaptorcable.
3.MinnKotatransducercable.
4.MinnKotatransducer.
38e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
