Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
151
Edition: Sept. 13, 2005 3646/110 --233.DOC010302
Serial
No.
Comments, InformationIndications
12.12 Indicate supporting liquid level
Indication “2.2” = liquid level OK
Indication “0” = liquid l evel not OK
Switch B 37 (DIP switch)
1 2345678
OPEN
B38
13X
B39
1X
(Li = Liquid)
12.13 Indicate operating voltage
Switch B 37 (DIP switch)
12345678
OPEN
B38
14X
B39
1X
