Installation and Service manual
Compass STD 22
Compass STD 22 Compact
152
Edition: Sept. 13, 2005
3646/110 --233.DOC010302
Serial
No.
Comments, InformationIndications
12.14 Indicate DC operating voltage for 400Hz
Switch B 37 (DIP switch)
1 2 345 67 8
OPEN
B38
15X
B39
1X
12.15 Indicate gyro supply
Switch B 37 (DIP switch)
1 2345678
OPEN
B38
16X
B39
1X
