Installation and Service manual
Compass STD 22
Compass STD 22 Compact
154
Edition: Sept. 13, 2005
3646/110 --233.DOC010302
Serial
No.
Comments, InformationIndications
12.18 Indicate internal operating voltage 15VDC
Switch B 37 (DIP switch)
12345678
OPEN
B38
19X
B39
1X
12.19 Indicate internal operating voltage 24VDC
Switch B 37 (DIP switch)
12345678
OPEN
B38
20X
B39
1X
