Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
155
Edition: Sept. 13, 2005 3646/110 --233.DOC010302
Serial
No.
Comments, InformationIndications
12.20 Indicate pump voltage 24V 50Hz
Switch B 37 (DIP switch)
1 2345678
OPEN
B38
21X
B39
1X
12.21 Indicate pump current
Switch B 37 (DIP switch)
12345678
OPEN
B38
22X
B39
1X
