Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
157
Edition: Sept. 13, 2005 3646/110 --233.DOC010302
Serial
No.
Comments, InformationIndications
12.24 Indicate program number and software version of the program for the
microprocessor on the sensor PCB.
Switch B 37 (DIP switch)
1 2345678
OPEN
B38
24X
B39
1X
12.25 Indicate program number and software version of the program for
microprocessor MC 1
on the outer sphere PCB.
Switch B 37 (DIP switch)
1 2345678
OPEN
B38
25X
B39
1X
