Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
7
Edition: May 20, 2005 3646/110 --233.DOC010302
24VDC
18 -- 36 V.d.c
AC/DC converter
121--062
Option:
or
Distribution Unit
138--118
Compass
STD 22
110 --233
Operator Unit
130--613
CAN bus
8x Heading (12x -- E10)
(course bus or NMEA)
3x Step
1x rate
of turn
1x RS232
for printer
STD 22 GGM Gyro Compass System
*
*(GGM = Gyro/Gyro/Magnet)
see manual no.:3648
see manual no.: 3647
Inputs:
-- NMEA Speed
-- NMEA Position
-- Pulse Log
-- Pulse Log Direction
NMEA Position
NMEA Speed
Pulse Log Direction
Pulse Log
Outputs:
Distribution Unit:
-- 8x Heading RMG course bus or NMEA
-- 3x Step (6 steps/degree), 24/35VDC, max. 10W
-- 1x RS232 serial interface for printer
-- 1x rate of turn +/-- 10V for 30/100/300 degrees/min
-- 12x Status (potential free)
CAN bus
Magnetic sonde
115--230VAC
50/60Hz
Compass
STD 22
110 --233
108--010
*
*The number of necessary
AC/DC converters depends on the neces-
sary max. power of all supplied devices
