Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
171
Edition: July 1, 2005 3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
17 PoS = Position – latitude in degrees.
12345678
OPEN
Switch B37 (DIP switch)
B39
16x
B38
No latitude data available
(GPS--receiver defective).
18 ASPd = Alarm “speed”
12345678
OPEN
Switch B37 (DIP switch)
B39
17x
B38
32
1
0
Digit 3 “Speed OK” Display 1 Speed OK
Display 0 Speed not OK
Digit 2 “Speed Alarm Display 1 Speed Alarm
Display 0 No Speed Alarm
Digit 1 “Auto Speed OK” Display 1 Auto Speed OK
Display 0 Auto Speed not OK
Digit 0 “Auto Alarm” Display 1 Auto Speed Alarm
Display 0 No Auto Speed Alarm
