Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Installation and Service manual
Compass STD 22
Compass STD 22 Compact
174
Edition: July 1, 2005
3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
23 nAn2 = 2nd table for NMEA--requests
12345678
OPEN
Switch B37 (DIP switch)
B39
22x
B38
1x
B38
1x
b = telegram type VBW
l = telegram type SLL
1st digit = number of b--types
2nd digit = number of l--types
24 nSGG = NMEA--telegram (Strings of the GGA--telegram)
12345678
OPEN
Switch B37 (DIP switch)
B39
23x
B38
The number of operations depends
on the number of characters.
(1 display content = max. 4 ASCII--
character)
See sequ. no 25
Number of ASCII--char-
acters per telegram
0000 = no telegram
