Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
175
Edition: July 1, 2005 3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
25 nSGL = NMEA--telegram (Strings of the GLL--telegram)
12345678
OPEN
Switch B37 (DIP switch)
B39
24x
B38
1x
B38
2x
B38
3x
B38
4x
B38
5x
B38
6x
Example:
Length of the telegram
= 44 ASCII--characters
