Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
181
Edition: July 1, 2005 3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
33
Development only!
FutG = Software component speed error correction: Course over ground
(Value of the VTG--telegram)
12345678
OPEN
Switch B37 (DIP switch)
B39
32x
B38
0000 = no telegram
123.4 = course value
34 tIME = Time since activating speed error correction.
(Reset with power--off)
12345678
OPEN
Switch B37 (DIP switch)
B39
33x
B38
1x
B38
2x
B38
3x
hours
days
(max. 99)
minutes
seconds
