Installation and Service manual
Compass STD 22
Compass STD 22 Compact
182
Edition: July 1, 2005
3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
35
Development only!
SCI . = Serial Communication Interface
(NMEA Log / GPS input)
12345678
OPEN
Switch B37 (DIP switch)
B39
34x
B38
The content of the two digits is during a
data transfer unrecognisable.
Just the digits 1
(16)
and 0
(16)
are visible for
a short moment; 10
(16)
means line feed.
All other sequentially indicated values are
for development purpose only.
