HandKey II Installation and Operation Manual
Page 26 Revision 2.0
* These signals are not currently supported.
Table 4: TS-3 - Card Reader and Output Connections
Terminal Connection
15 +5 VDC @ 400 mA Max. Output for External Card Reader
16 Card Reader: Wiegand D0 or Magnetic Stripe Data Input
17 Card Reader: Wiegand D1 or Magnetic Stripe Clock Input
18 Card Reader Ground
19 Lock Output or Wiegand D1 or Magnetic Stripe Clock Output
20 Ground
21 Auxiliary Output 0 or Wiegand Data 0 or
Magnetic Stripe Data Output
22 Ground
23 Auxiliary Output 1
24 Ground
25 Auxiliary Output 2
26 Ground
Table 5: RJ-45 Serial RS-232 Connection
Pin Signal Connection
1 RI * Ring Indicator Input
(from external device)
2 CD * Carrier Detect Input
(from external device)
3 DTR * Data Terminal Ready Output (to external device)
4 GND Ground
5 Rx Data Receive Data Input (from external device)
6 Tx Data Transmit Data Output (to external device)
7 CTS * Clear to Send Input (from external device)
8 RTS * Ready to Send Output (to external device)
