Table 19: CLI - get
wetxpktdis
Wireless Eth Tx discarded packets.
wetxpkterr
Wireless Eth Tx packets with errors.
5.3.10 load
Use the load command to install encryption keys into the RDL-3000.
Table 20: CLI - load
Load stored information from non volatile RAM or a remote server.
load <file> <idtable> <script>
file <server IP> <filename> <usr | factory | fips> <tftp | sftp> <user> <password>
Load a key or certificate file from FTP server. The file is saved in non volatile RAM area. A
reboot is required to activate changes to security data. The filename must be one of the
following:
dsa_key_<mac>.pem DSA key used for SSH.
rsa_key_<mac>.pem* RSA Key used for SSH.
ssl_cert_<mac>.pem SSL Certificate.
ssl_key_<mac>.pem SSL Key.
usr_wcert_<mac>.der** User wireless certificate.
usr_wkey_<mac>.der User wireless key.
usr_wacert_<mac>.der User wireless authority certificate.
The <mac> portion is the MAC address of the board.
For example: dsa_key_00-09-02-00-01-02.pem
Specify where to store the security information.
usr User entered files (default if type is not specified).
factory Default files.
fips FIPS mode files (FIPS mode must be active).
For example:
load file 192.168.25.10 ssl_key_00-09-02-00-b2-73.pem usr tftp
idtable (no parameters)
Load all IDs from flash memory. This can be used to restore all IDs from the last saved
configuration.
script <server IP> <filename>
Use this command to load the RDL-3000 configuration information from a file (created
using script command) located on a remote TFTP server. The file must be located in the
TFTP default directory. The 'save config' command must be used to save the loaded
configuration in non volatile memory. A reboot may be required to activate the loaded
configuration settings.
For example:
load script 192.168.25.10 RDL3000-Unit035-091121.cfg
