8.2.2 Packet Classification at the Subscriber
The RDL-3000 PMP deployment can be configured for use with VLAN tagged traffic,
untagged traffic, or a combination these two types. Ingress packets received on the
subscriber Ethernet port are classified according to the criteria in the following table.
Table 42: Spec. - Classification: Packet Received on SS Ethernet Port
VLAN tag matches a Service VID
Known unicast
Priority: Preserve original 802.1p priority bits.
Tag: Remove outermost matching VLAN tag.
Forward: To sector controller.
Rate: Uplink rate of Service matching this tag.
Unknown unicast:
Priority: Preserve original 802.1p priority bits.
Tag: Remove outermost matching VLAN tag.
Forward: To sector controller.
Rate: Uplink rate of Service matching this tag.
Known multicast or
broadcast:
Priority: Preserve original 802.1p priority bits.
Tag: Remove outermost matching VLAN tag.
Forward: To sector controller.
Rate: Uplink rate of Service matching this tag.
VLAN tag does not match any Service VID -- OR -- untagged packet
Pass through service
group not defined:
Discard packet.
Pass through service
group defined
--- AND ---
known unicast
Priority: Service Group default priority.
Tag: Unchanged
Forward: To sector controller.
Rate: Uplink rate of (Pass through) member Service.
Pass through service
group defined
--- AND ---
unknown unicast
Priority: Service Group default priority.
Tag: Unchanged
Forward: To sector controller.
Rate: Uplink rate of (Pass through) member Service.
Pass through service
group defined
--- AND ---
multicast or broadcast
Priority: Service Group default priority.
Tag: Unchanged
Forward: To sector controller.
Rate: Uplink rate of (Pass through) member Service.
Notes: 1 If SS to SS Multicast enabled.
Table 43: Spec. - Classification: Packet Received on SS Wireless Interface
Member of Service Group type: Tagged
Any type
Priority: Use priority received with packet
Tag: Add VLAN tag (outermost) for this Service
(Q in Q).
Forward: To subscriber Ethernet port.
Member of Service Group type: Pass through
Any type
Forward packet unmodified to the subscriber Ethernet port
.
