RL78/F13, F14 CHAPTER 16 SERIAL INTERFACE IICA
R01UH0368EJ0210 Rev.2.10 1028
Dec 10, 2015
16.3.3 IICA status register 0 (IICS0)
This register indicates the status of I
2
C.
The IICS0 register is read by a 1-bit or 8-bit memory manipulation instruction only when STT0 = 1 and during the
wait period.
Reset signal generation clears this register to 00H.
Caution Reading the IICS0 register while the address match wakeup function is enabled (WUP0 = 1) in
STOP mode is prohibited. When the WUP0 bit is changed from 1 to 0 (wakeup operation is
stopped), regardless of the INTIICA0 interrupt request, the change in status is not reflected until
the next start condition or stop condition is detected. To use the wakeup function, therefore,
enable (SPIE0 = 1) the interrupt generated by detecting a stop condition and read the IICS0 register
after the interrupt has been detected.
Remark STT0: bit 1 of IICA control register 00 (IICCTL00)
WUP0: bit 7 of IICA control register 01 (IICCTL01)
Figure 16-7. Format of IICA Status Register 0 (IICS0) (1/3)
Address: FFF51H After reset: 00H R
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
IICS0 MSTS0 ALD0 EXC0 COI0 TRC0 ACKD0 STD0 SPD0
MSTS0 Master status check flag
0 Slave device status or communication standby status
1 Master device communication status
Condition for clearing (MSTS0 = 0) Condition for setting (MSTS0 = 1)
When a stop condition is detected
When ALD0 = 1 (arbitration loss)
Cleared by LREL0 = 1 (exit from communications)
When the IICE0 bit changes from 1 to 0 (operation
stop)
Reset
When a start condition is generated
ALD0 Detection of arbitration loss
0 This status means either that there was no arbitration or that the arbitration result was a “win”.
1 This status indicates the arbitration result was a “loss”. The MSTS0 bit is cleared.
Condition for clearing (ALD0 = 0) Condition for setting (ALD0 = 1)
Automatically cleared after the IICS0 register is read
Note
When the IICE0 bit changes from 1 to 0 (operation
stop)
Reset
When the arbitration result is a “loss”.
Note This register is also cleared when a 1-bit memory manipulation instruction is executed for bits other
than the IICS0 register. Therefore, when using the ALD0 bit, read the data of this bit before the data
of the other bits.
Remark LREL0: Bit 6 of IICA control register 00 (IICCTL00)
IICE0: Bit 7 of IICA control register 00 (IICCTL00)
