RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1484
Dec 10, 2015
21.3 Registers Controlling Interrupt Functions
The following 9 types of registers are used to control the interrupt functions.
 Interrupt request flag registers (IF0L, IF0H, IF1L, IF1H, IF2L, IF2H, IF3L)
 Interrupt mask flag registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H, MK3L)
 Priority specification flag registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H, PR03L, PR10L, PR10H, PR11L,
PR11H, PR12L, PR12H, PR13L)
 External interrupt rising edge enable registers (EGP0, EGP1)
 External interrupt falling edge enable registers (EGN0, EGN1)
 Interrupt source determination flag register 0 (INTFLG0)
 Interrupt mask register (INTMSK)
 Input switch control register (ISC)
 Program status word (PSW)
Table 21-2 shows a list of interrupt request flags, interrupt mask flags, and priority specification flags corresponding to
interrupt request sources.
Table 21-2. Flags Corresponding to Interrupt Request Sources (1/4)
Interrupt
Source
Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag
100-pin 80-pin 64-pin 48-pin 32-pin 30-pin 20-pin
Register Register Register
INTWDTI WDTIIF IF0L WDTIMK MK0L WDTIPR0, WDTIPR1 PR00L,
PR10L
      
INTLVI LVIIF LVIMK LVIPR0, LVIPR1
      
INTP0 PIF0 PMK0 PPR00, PPR10
      
INTP1 PIF1 PMK1 PPR01, PPR11
      
INTP2 PIF2 PMK2 PPR02, PPR12
      
INTP3 PIF3 PMK3 PPR03, PPR13
      
INTP4 PIF4 PMK4 PPR04, PPR14
      
INTSPM SPMIF SPMMK SPMPR0, SPMPR1
      
INTP5 PIF5 PMK5 PPR05, PPR15
  
   
INTCMP0 CMPIF0 CMPMK0 CMPPR00, CMPPR10

Note

Note

Note

Note

Note

Note

Note Provided only in products of Groups D and E.
